Assessing PV cell, module reliability via Arrhenius equation

Researchers in Portugal have used the so-called Arrhenius aging model to measure the temperature behaviour and reliability of different solar modules. Their analysis showed that long-term module performance can diverge significantly depending on the manufacturing processes.

A group of scientists led by Portuguese research center Instituto de Telecomunicações and the University of Lisbon has utilized the so-called Arrhenius equation to assess the reliability of monocrystalline PV cells and modules.

The Arrhenius aging model is an empirical equation that describes the effect of temperature on the velocity of a chemical reaction. It is the basis of all predictive expressions used for calculating reaction-rate constants.

The Arrhenius model describes the collision between charge carriers – electrons and holes – for different temperatures,” the research's corresponding author, Ricardo A. Marques Lameirinhas, told pv magazine. “Electronic devices age due to carriers collisions, then this model is suitable to characterise the ageing processes of any electronic and optoelectronic device, as solar cells. This is done by accelerated ageing processes and considering temperature cycles in ovens at high temperatures. ”

The scientists tested several small-sized monocrystalline solar modules provided by Chinese providers Seed Studio and Osepp in different time intervals for 135 h at constant temperatures from 65 C to 95 C, with the accelerated ageing temperature being conducted by controlling only the temperature.

“This combination of time and temperature led us to have operation times around thousands of hours, for instance, 135 h at 95 C is equivalent to more than thousand hours at nominal operation at 48 C,” Lameirinhas stated “Thus, we verified that the power degradation follows a logarithmic decline trend with temperature, as expected by the Arrhenius ageing model.”

In the study “Experimental determination of Arrhenius degradation coefficients for monocrystalline photovoltaic solar cells,” published in Results in Optics, Lamerinhas and his research group explained they measured current and voltage through GW Instek GDM-8135 multimeters, both in DC Voltage mode.

“The I-V points are obtained one by one, reducing noise and ensuring the same load conditions for each resistance for different tests,” the academics stressed. “To ensure the repeatability of the tests and the validation of the model that is created from the test results, all the tests are conducted using three identical PV solar cells, using a 50 W light with a light temperature of 6400 K, under 84 W/m

.”

The measurements showed that all tested cells and panels suffered from “high” degradation for open-circuit voltage and maximum power and “moderate” degradation for short-circuit current. The Seeed Studio modules were found to lose 10% of their maximum power in 12 years and 5 months, while the Osepp panels lost the same percentage in 45 years and 1 month. The big difference in reliability was attributed by the scientists to different manufacturing processes and the related module quality.

“This fact leads one to conclude that the reliability of some solar cells that are available in the market cannot be assured,” the scientists concluded. “Within the 25-year commercial warranties the results also suggest that both power and voltage characteristics will decay between 10% to 15%.”

Other researchers from Chinese module maker Trina Solar recently adopted the Arrhenius model to predict the field degradation from potential induced degradation (PID) for tunnel oxide passivated contacts (TOPCon) double-glass module configuration with double ethylene vinyl acetate (EVA) as an encapsulant.
